Specifications

• Video
• Sensor: 2.0 megapixel 1/2.8″ SONY307 Star Light CMOS
• Video resolution: Main stream: 1920×1080@25fps, Sub stream: 640×352@25fps
• Video compression: H.265
• Lens: Optional 2.8/3.6(default)/6mm lens
• View angle: 89.9°/75.7°(default)/50° based on lens
• Night vision: 6pcs array infrared LEDs, night vision distance 25m
• Audio
• Audio compression: G.726/G.711
• Audio code rate: 8Kbps, 16bit
• Audio input/output: Built-in MIC and speakers, support two way audio
• Alarm
• Motion detecting alarm: Can set 4 independent detection region (1-100 sensitivity can be set)
• Alarm linkage:
• – Alarm send pictures to the mailbox,
• – Alarm upload pictures and videos to the FTP server,
• – Alarm record pictures and videos to Micro SD card,
• – Alarm mobile phone message push,
• – Alarm trigger sound alarm
• Alarm recording; Support Micro SD card and PC client linkage alarm recording
• Network
• Wireless: IEEE 802.11 b/g/n
• Ethernet: RJ45 Ethernet
• Onvif protocol: Support ONVIF 2.4(backward compatible)
• Storage
• Micro SD card: Support up to 128G micro SD card
• Recording mode: Alarm record, timing record,
• Video playback: Support APP, IE browser, remote client play and download the video
• General specifications
• Power: DC12V 1A. (sold separately)
• Operating temperature: -20℃~+60℃
• Operating Humidity: 10%～90%, non-condensing
• Shell material: All metal shell
• Waterproof level: IP66
• Product size: 175mm×62mm×66mm(L×W×H)
• Product weight: 0.35kg
• Package size: 218mmx158mmx106mm(L×W×H)
• Package weight: 0.6kg
• Reset button: Support
