25 Channel / 16 Channel x PoE 4K Network Video Recorder
25 Channel / 16 Channel x PoE 4K Network Video Recorder

25 Channel / 16 Channel x PoE 4K Network Video Recorder

$879.95

Our 16ch 4K NVR with 8 x PoE & P2P Remote View is a great and easy to configure NVR.  Compatible with  HikVision Dahua and Onvif cameras.

SKU - DEAL16CHNVR

Description

Overview

This 25 Channel / 16 Channel x PoE 4K Network Video Recorder offers 5MP resolution recording at 25fps for up to 25 cameras (or 12ch of 4K @ 25fps). For ease of installation, 16 dedicated PoE ports are in-built. It utilises H.264/H.265+ compression to maximise your hard disk space and has wide camera compatibility with ONVIF 2.4 support. Recording can be manually set, scheduled or triggered by motion detection. Supports four internal hard disks, maximum storage 32TB. Hard drives sold separately.

Download the platform software guide suitable for windows and mac

Features

  • H.264+/265+ compression
  • 4K HDMI monitor output
  • Recording 25 channels up to 5MP @ 25fps per ch
  • Supports iOS and Android remote viewing
  • 16 x 15.4W PoE network interfaces
  • Four internal SATA interface, max 32TB
  • Remote control & mouse
  • USB backup
  • Dedicated network interface
  • Audio input & output
  • ONVIF 2.4 support

 Specifications

  • System
  • Main Processor: ARM Cortex A7 Processor
  • Operating System: Embedded LINUX
  • Video
  • Input: 25CH (4096×2160, 2592×1944, 2048×1536, 1920×1080, 1280×960, 1280×720, etc)
  • Output:1 VGA, 1 HD
  • Audio
  • Input:1 Port RCA
  • Output: 1 Port RCA(Linear, 1kΩ)
  • Audio Bit Rate: 64kbps
  • Audio Compression standard: G711u, G711a
  • Alarm
  • Sensor Input: 16CH Input
  • Output: 4CH Output
  • Motion Detection: 25 Channel, MD Zones: 396 (22 × 18)
  • Trigger Events: Recording, Email, FTP, Snapshot, Buzzer and Screen Tips, alarm output
  • Display
  • HD Output: Resolution:4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
  • VGA: Resolution:1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
  • Display Split: 25CHxD1/16CHxD1/9CHxD1/4CHxD1/1CHx1080P/1CHx3MP/1CHx4MP/1CHx5MP/1CHx4k/1CHx12MP
  • Digital Zoom: YES
  • OSD: Camera Title, Time, Recording, Motion Detection
  • Recording
  • Video Compression: H265/H264/H265+/H264+
  • Resolution: 4k(4096×2160),5MP(2592×1944),4MP(2688×1520/2560×1440),3MP(2048×1536),1080P(1920×1080),960P(1280×960),720P(1280×720),D1 (720×576/720×480)
  • Record Rate: PAL :4k@12×25fp,5MP@20×25fp,4MP@25x25fp,3MP@25×25fp,1080P@25×25fp, 960P@25×25fp,720P@25×25fp, D1@25×25fp
  • NTSC: 4k@12×30fp,5MP@20×30fp,4MP@25×30fp,3MP@25×30fp,1080P@25×30fp, 960P@25×30fp, 720P@25×30fp, D1@25×30fp
  • Record Mode: Manual Timer Motion Detection
  • Playback & Backup
  • Local Sync Playback: 1CH 4K@30fps, 1CH 5MP@30fps,2CH 4MP@30fps, 2CH 3M@30fps, 4CH 1080P@30fps, 4CH 960P@30fps, 4CH 720P@30fps
  • Decode Capability: 1CH 4K(3840×2160)@30fps
  • Remote Sync Playback: YES
  • Search Mode: ALL, Channel, Manual, Time, Date, Motion Detection
  • Playback Functions: Play, Pause, Stop, Fast Play, Digital Zoom
  • Backup Mode: USB Device/Network
  • Network
  • Interface: 16 x RJ45 (10M/100M Adaptive Ethernet Interface)+1xRJ45 10M/100M/1000M Adaptive Ethernet Interface
  • Incoming Bandwidth: 120MB
  • Network Functions: TCP/CP, HTTP, UPnP, DNS, NTP, SMTP, PPPoE, DHCP, FTP, DDNS, RTP, RTSP, RTCP, p2p
  • Onvif Version: Support Onvif 2.4
  • Web Browser: IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53)
  • CMS Software: Support Windows 7/ Windows 8/Windows 10
  • Cloud Support(P2P)Yes
  • Smart Phone: iPhone, iPad, Android, Android Pad
  • POE: 16 x Independent 100Mbps POE Network Interfaces(Output PowerAT mode 30W, AF mode 15W per Interface), 12/36 line order, Total Power Output≧200W, Support Plug and Play
  • Storage
  • Interface Type: 4 SATA Interface
  • Capacity: Up to 32TB capacity
  • General
  • Languages: Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, Farisa, German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, Korean, Dutch, Greek
  • USB Interface: 2 USB 2.0 Interfaces
  • RS485: 1xRS485
  • Power Supply: AC 100-240V
  • Working Environment: -10~55℃/10~90%
  • Dimensions: (W×D×H)493*367*69(mm)
  • Weight: 9.8kg (without HDD)
