16 Channel / 8 Channel x PoE 4K NVR
16 Channel / 8 Channel x PoE 4K NVR

16 Channel / 8 Channel x PoE 4K NVR

$589.95

Our 16ch 4K NVR with 8 x PoE & P2P Remote View is a great and easy to configure NVR.  Compatible with  HikVision Dahua and Onvif cameras.

SKU - DEAL8CHNVR

Description

Overview

This multi channel network video recorder offers 8MP resolution recording at 25fps for up to 10 cameras (or 16ch of 5MP @ 25fps). For ease of installation, 8 dedicated PoE ports are in-built. It utilises H.264/H.265+ compression to maximise your hard disk space and has wide camera compatibility with ONVIF 2.8 support. Recording can be manually set, scheduled or triggered by motion detection. Supports one internal hard disk, maximum storage 8TB. Hard drives sold separately.

Features

  • H.264+/265+ compression
  • 4K HDMI monitor output
  • Recording 10 channels up to 8MP @ 25fps per ch
  • Supports iOS and Android remote viewing
  • 8 x 15.4W PoE network interfaces
  • One internal SATA interface, max 8TB
  • USB backup
  • Dedicated network interface
  • Audio input & output
  • ONVIF 2.8
  • Support Plug and Play
  • Support network cable extended mode – Max. 200M

Specifications

  • System
  • Main Processor: ARM Cortex A7 Processor
  • Operating System: Embedded LINUX
  • Video
  • Input: 16CH (3840×2160, 2592×1944, 2048×1536, 1920×1080, 1280×960, 1280×720, etc)
  • Output: 1 VGA, 1 HD
  • Audio
  • Input: 1 Port RCA, support 16CH IPC audio input
  • Output: 1 Port RCA (Linear, 1kΩ), HD output
  • Audio Bit Rate: 64kbps
  • Audio Compression standard: G711u, G711a, ADPCM_DVI4
  • Alarm
  • Sensor Input: 4
  • Output: 1
  • Motion Detection: 16 Channel, MD Zones: 396 (22 × 18)
  • Trigger Events: Recording, Email, FTP, Snapshot, Buzzer and Screen Tips, alarm output
  • Display
  • HD Output: 4K (3840*2160), 1920*1080, 1280*1024, 1280*720, 1024*768
  • VGA: Resolution: 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
  • Display Split: 16CHxD1/9CHxD1/8CHxD1/4CHxD1/1CHx1080P/1CHx3MP/1CHx4MP/1CHx5MP/1CHx4K
  • Digital Zoom: YES
  • OSD: Camera Title, Time, Recording, Motion Detection, Event Alarm
  • Recording
  • Video Compression: H265/H264/H265+/H264+
  • Resolution: 4K(3840×2160), 5MP(2592×1944), 4MP(2688×1520/2560×1440), 3MP(2048×1536), 1080P(1920×1080), 960P(1280×960), 720P(1280×720), D1 (720×576/720×480)
  • Record Rate: PAL: 4K@10x25fps, 5MP@16×25fp, 4MP@16x25fp, 3MP@16×25fp, 1080P@16×25fp, 960P@16×25fp, 720P@16×25fp, D1@16×25fp
  • NTSC: 4K@10x30fps, 5MP@16×30fp, 4MP@16×30fp, 3MP@16×30fp, 1080P@16×30fp, 960P@16×30fp, 720P@16×30fp, D1@16×30fp
  • NTSC: 4K@10x30fps, 5MP@16×30fp, 4MP@16×30fp, 3MP@16×30fp, 1080P@16×30fp, 960P@16×30fp, 720P@16×30fp, D1@16×30fp
  • Record Mode: Manual/Timer/Motion Detection/Alarm/Smart Event
  • Playback & Backup
  • Local Sync Playback: 1CH 4K@30fps, 1CH 5MP@30fps,2CH 4MP@30fps, 2CH 3M@30fps, 4CH 1080P@30fps, 4CH 960P@30fps, 4CH 720P@30fps,16CH D1@30fps
  • Decode Capability: 4CH 1080P (1920×1080) @30fps
  • Remote Sync Playback: YES
  • Search Mode: ALL, Timing Video, Motion Detection, Alarm, Tag, Search, Smart Event, Picture, Log
  • Playback Functions: Play, pause, fast forward, rewind, previous frame, next frame, electronic zoom, clip, audio
  • Backup Mode: USB Device/Network
  • Network
  • Interface: 1xRJ45 10M/100/1000M Adaptive Ethernet Interface
  • Incoming Bandwidth: 120MB
  • Network Functions: TCP/IP, HTTP, HTTPS, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p, PPPOE
  • Onvif: onvif S,onvif T
  • Web Browser: Edge,IE8-11, Google Chrome , Firefox ,Safari
  • CMS Software: Support Windows 7/ Windows 8/Windows 10/MAC OS
  • Cloud Support (P2P): Yes
  • Smart Phone: iPhone, iPad, Android, Android Pad
  • POE: 8 x Independent 100Mbps POE Network Interfaces (Output power AF mode 15W per port), 45/78 line order
  • Total Power Output: ≤ 96W
  • Support Plug and Play
  • Support network cable extended mode Max. 200M
  • Storage
  • Interface Type: 1 SATA Hard Disk Interface (2.5″/3.5″ SATA)
  • Capacity: Up to 8TB capacity
  • General
  • Language: Simplified Chinese, English, Russian, Deutsch, French, Portuguese, Spanish, Italian, Korean, Japanese
  • USB Interface: 2 USB 2.0 Interfaces
  • Power Supply: DC48V∕2500mA
  • Working Environment: -10~50℃/10~90%
  • Dimensions: 260W x 230D x 43H(mm)
  • Weight: 2.0KG (without HDD)
